ALS-PDIC243-3B LED Lighting Components Optical Sensor Ambient 590nm
Current Radial
Ambient Light Sensor 5mm T-1 3/4 ALS-PDIC243-3B
Features
‧Excellent IR-Cut performance
‧Close responsively to the human eye spectrum
‧Light to Current, analog output
‧Good output linearity across wide illumination range
‧Low sensitivity variation across various light sources
‧Operation temperature performance, -40oC to 85oC
‧Wide supply voltage range, 1.8V to 5.5V
‧Size: 5mm Lamp (Flat lens)
‧RoHS compliant package
Description
The ALS-PDIC243-3B is an ambient light sensor, which incorporates a
photodiode and a current amplifier IC in DIP package. EVERLIGHT ALS
series products are a good effective solution to the power saving
of display backlighting of mobile appliances, such as the mobile
phones, NB and PDAs. Due to the high rejection ratio of infrared
radiation, the spectral response of the ambient light sensor is
close to human eyes. Also, it is very suitable to use ALS product
for opto-switch application.
Applications
‧Ambient light monitoring device for daylight and artificial light
– CCD camera/CCTV security equipment, Street light
‧Detection of ambient light to control display backlighting
Computing device – TFT LCD monitor for Notebook computer Consumer
device – TFT LCD TV, video camera, digital camera,
toysALS-PDIC243-3B LED Lighting Components Optical Sensor Ambient
590nm Current Radial
| Product Attributes | Select All |
| Categories | Sensors, Transducers |
| | Optical Sensors - Ambient Light, IR, UV Sensors |
| Manufacturer | Everlight Electronics Co Ltd |
| Series | - |
| Packaging | Bulk |
| Part Status | Obsolete |
| Type | Ambient |
| Wavelength | 590nm |
| Proximity Detection | No |
| Output Type | Current |
| Voltage - Supply | 1.8 V ~ 5.5 V |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Supplier Device Package | T-1 3/4 |
