ACPL-247 Optoisolator Transistor Output 3000Vrms 4 Channel 16-SO

DC Input, Multi-Channel Half-Pitch Phototransistor Optocoupler

Description
The ACPL-227 is a DC-input dual-channel half-pitch
phototransistor optocoupler that contains two light-emitting
diodes optically coupled to two separate phototransistors. It is
packaged in an 8-pin SO package.
Likewise, the ACPL-247 is a DC-input quad-channel half-pitch
phototransistor optocoupler that contains four light-emitting
diodes optically coupled to four separate phototransistors. It is
packaged in a 16-pin SO package.
For both devices, the input-output isolation voltage is rated at
3750VRMS. Response time, tr, is 2 μs typically, while minimum
CTR is 50 percent at input current of 5 mA.

Features

Current transfer ratio
(CTR: 50% (min) at IF = 5 mA, VCE = 5V)
High input-output isolation voltage
(VISO = 3750VRMS)
Non-saturated response time
(tr: 2 μs (typ) at VCC = 10V, IC = 2 mA, RL= 100)
SO package
CMR 10 kV/μs (typical)
Safety and regulatory approvals
— cUL
— IEC/EN/DIN EN 60747-5-5
Options available:
— CTR Ranks 0, B, and C for ACPL-227 and Rank 0 only for
ACPL-247

Applications
I/O Interface for programmable controllers, computers
Sequence controllers
System appliances, measuring instruments
Signal transmission between circuits of different potentials
and impedances
