PMD2409PMB3 A Other Electronic Components 92x38mm 24V DC Fan 3800RPM 0.43 Inch

Ask Lasest Price
Brand Name :	SUNON
Model Number :	PMD2409PMB3-A
Price :	Negotiation
Payment Terms :	T/T, Western Union,paypal
Supply Ability :	10000PCS
Delivery Time :	3-5days

Add to Cart

Product Details
Company Profile

PMD2409PMB3 A Other Electronic Components 92x38mm 24V DC Fan 3800RPM 0.43 Inch

PMD2409PMB3-A Other Electronic Components DC Fans 92x38mm,

24VDC, 91.7CFM, 6W, 50.3dBA, 3800RPM,0.43inch

Standard SUNON 9238 92x92 38mm 92x92

Cooling Fan Ventilation Axial Flow 24V DC Fan 92x92x38 mm

(PMD2409PMB3-A.(2).GN)

Product details
Manufacturer: Sunon
Product Category: DC Fans
RoHS: Details
Product: DC Brushless Fans
Type: Axial
Frame Dimensions - mm: 92 mm L x 38 mm W x 92 mm H
Operating Supply Voltage: 24 VDC
Airflow: 91.7 CFM
Speed: 3800 RPM
Pressure Type: 0.43 in H2O
Bearing Type: Ball
Noise: 50.3 dBA
Power Rating: 6 W
Termination Style: Wire Leads
Series: PMD
Height: 92 mm
Length: 92 mm
Size: 92 mm x 38 mm
Width: 38 mm
Brand: Sunon
Current Type: DC
Product Type: DC Fans
Factory Pack Quantity: 1
Subcategory: Fans, Blowers & Accessories
Unit Weight: 6.702053 oz

Product Description

Model	Bearing	Rating Voltage	Power Current	Power Consumption	Speed	Air Flow	Static Pressure	Noise	Weight
Model	2:2Ball	(VDC)	(mA)	(WATTS)	(RPM)	(CFM)	(Inch-H2O)	(dB(A))	(g)
PMD1209PMB1-A.(2).GN (92x92x38mm)	2	12	1040	12.5	4900	120.2	0.71	57.6	190.0
PMD1209PMB2-A.(2).GN (92x92x38mm)	2	12	710	8.5	4400	106.3	0.56	53.8	190.0
PMD1209PMB3-A.(2).GN (92x92x38mm)	2	12	470	5.6	3800	91.7	0.43	50.3	190.0
PMD1209PMB4-A.(2).GN (92x92x38mm)	2	12	290	3.5	3200	75.1	0.3	45.6	190.0
PMD2409PMB1-A.(2).GN (92x92x38mm)	2	24	510	12.2	4900	120.2	0.71	57.6	190.0
PMD2409PMB2-A.(2).GN (92x92x38mm)	2	24	400	9.6	4400	106.3	0.56	53.8	190.0
PMD2409PMB3-A.(2).GN (92x92x38mm)	2	24	250	6.0	3800	91.7	0.43	50.3	190.0
PMD2409PMB4-A.(2).GN (92x92x38mm)	2	24	170	4.1	3200	75.1	0.30	45.6	190.0

Standard SUNON 9238 92x92 38mm 92x92 Cooling Fan Ventilation Axial Flow 24V DC Fan 92x92x38 mm (PMD2409PMB3-A.(2).GN)

PMD2409PMB3 A Other Electronic Components 92x38mm 24V DC Fan 3800RPM 0.43 Inch

Deli electronics tehcnology Co.,Ltd.
www.icmemorychip.com
Email:sales3@deli-ic.com
Skype:hkdeli881
Contact: VIVI-CHEN
