275nm UVC LED Lamp Bacteria Disinfection Sterilizer DC5V 5mW Ultra Violet Light Strip

Ask Lasest Price
Brand Name :	DELI
Model Number :	DLBD-UVC275-5
Price :	negotiaon
Payment Terms :	T/T, Western Union, paypal
Supply Ability :	10000
Delivery Time :	3-5days

Add to Cart

Product Details
Company Profile

275nm UVC LED Lamp Bacteria Disinfection Sterilizer DC5V 5mW Ultra Violet Light Strip

5mW DUV UVC Light Fixtures DC 5V Ultra Violet Light Strip 275nm Bacteria Sterilizer

Application: Medical sterilization / home disinfection / outdoor disinfection,

Industrial disinfection

Features:
1. High performance: Kill 99.99% of harmful bacteria with UV light in seconds.
2. DIY Water Sanitizer solution: Clean water by installing a UVC LED module.
3. Environmental friendly: Chemical-free ultroviolet lighting source.
4. Long serving life: Nearly 10000 hours of working life.
5. Instant start.

Parameters:

Power: 5mW

Voltage: DC5V

Weight: 25g

Size: 25*1*0.2cm

Part one:

PCB Board Size Map(mm)

Material of the PCB board is double-sided glass fiber.

The outline dimension is 250mm*10mm, the depth of the PCB board is 1.6mm,

IC and Resistor on the back (depth:2mm) and UVC LED (1.6mm) on the front.

The overall depth is around 4.3mm.

Part two:

Technical Requirement

It has violet LEDs and 1 UVC LEDs on the PCB board.

A. Table of the parameters of the 2 blue LEDs

Item	Symbol	Condition	Min.	Ave.	Max.	Unit
Forward Voltage	VF	IF=30mA	3.2		3.6	V
Reverse Current	IR	VR=5V	--		10	μA
Light Angle	2θ½	IF=30mA	--	120	--	deg
Luminous Flux	φV	IF=30mA	40		80	mw
Working Current	IF	--	--	30	--	mA
Peak Wavelength	λP	IF=30mA	395	--	400	nm
Junction Temperature	Tj	IF=30mA	--	125	--	℃
Thermal Resistance	RJP	IF=30mA	--	8	--	℃/W

B. Table of the parameters of 1 UVC LED

Item	Symbol	Condition	Min.	Ave.	Max.	Unit
Forward Voltage	VF	IF=40mA	5	6.5	8	V
Light Angle	2θ½	IF=40mA	--	120	--	deg
P-out	P	IF=40mA	2	3.5	5	mW
Half-Wave Width	Δλ	IF=40mA	8	10	12	nm
Peak Wavelength	λP	IF=40mA	270	275	285	nm
ESD	H.B.M	--	4000	-	-	V

Part three: Description of Wire

Length: 500mm; 24AWG; Red: Anode; Black: Cathode;

Terminal: 2 pin mini jst socket

Part four: Power Supply DC5V

275nm UVC LED Lamp Bacteria Disinfection Sterilizer DC5V 5mW Ultra Violet Light Strip

Deli electronics tehcnology co ltd
www.icmemorychip.com
www.uvc-led.net
Email:sales3@deli-ic.com
Skype:hkdeli881
Contact: VIVI-CHEN
