    24-16AWG Terminal Block Connector DL2EDG-VK-XX-3.81 M2 Steel Zinc Plated Screw

    Ask Lasest Price
    Brand Name : DELI
    Model Number : DL2EDG-VK-XX-3.81
    Supply Ability : 10000
    Delivery Time : 2DAYS
    Payment Terms : T/T, Western Union
    • Product Details
    • Company Profile

    24-16AWG Terminal Block Connector DL2EDG-VK-XX-3.81 M2 Steel Zinc Plated Screw

    MATERIAL
    Pitch:3.81MM
    Poles: 2P-24P
    Screw:M2,Steel, Zinc plated
    Wire cage: Brass, Ni plated
    Contact: Brass, Tin plated
    Housing:PA66. UL94V-0
    ELECTRICAL
    Rated voltage:IEC:250V UL:300V
    Rated current: IEC:7A UL:8A
    Withstanding voltage:AC2000V/1Min
    Wire range:24-16AWG
    MECHANICAL
    Temperature range:-40℃-- +105℃
    MAX soldering:+250℃ for 5 sec
    Torque:0.2Nm(1.8 lb.in)
    Strip length:7-8mm
    24-16AWG Terminal Block Connector DL2EDG-VK-XX-3.81 M2 Steel Zinc Plated Screw
