    Good quality 2.54mm pcb terminal block DL141V-XX-2.54

    Ask Lasest Price
    Brand Name : DELI
    Model Number : DL141V-XX-2.54
    Payment Terms : T/T, Western Union
    Supply Ability : 10000
    Delivery Time : 2DAYS
    • Product Details
    • Company Profile

    Good quality 2.54mm pcb terminal block DL141V-XX-2.54

    MATERIAL
    Pitch:2.54MM
    Poles: 1P-xxP
    Pin header:Brass ,Tin plated
    Clips:Stainless Steel
    Housing:PA66. UL94V-0
    ELECTRICAL
    Rated voltage:150V/130V
    Rated current:2A/6A
    Withstanding voltage:AC1250V/1Min
    Wire range:26-20AWG
    MECHANICAL
    Temperature range:-40℃-- +105℃
    MAX soldering:+250℃ for 5 sec
    Strip length:11mm
    Good quality 2.54mm pcb terminal block DL141V-XX-2.54
    DeLi Electronics Technology Co., Ltd
    PART# :DL141V-XX-2.54
