    PCB Screw Down Terminal Block 57A/65A 2P 3P Poles 10.16 Pitch DL136T-XX-10.16

    Ask Lasest Price
    Brand Name : DELI
    Model Number : DL136T-XX-10.16
    Payment Terms : T/T, Western Union
    Supply Ability : 10000
    Delivery Time : 2DAYS
    • Product Details
    • Company Profile

    PCB Screw Down Terminal Block 57A/65A 2P 3P Poles 10.16 Pitch DL136T-XX-10.16

    MATERIAL
    Pitch:10.16MM
    Poles: 2P,3P
    Screw:M4, Steel,Zinc plated, Brass,Ni plated
    Wire cage: Brass,Ni plated
    Pin header: Brass,Tin plated
    Housing:PA66. UL94V-0
    ELECTRICAL
    Rated voltage:750V/1000V
    Rated current:57A/65A
    Withstanding voltage:AC3000V/1Min
    Wire range:20-6AWG
    MECHANICAL
    Temperature range:-40℃-- +105℃
    MAX soldering:+250℃ for 5 sec
    Torque:1.7Nm(15.0 lb.in)
    Strip length:10mm
    PCB Screw Down Terminal Block 57A/65A 2P 3P Poles 10.16 Pitch DL136T-XX-10.16
    DeLi Electronics Technology Co., Ltd
    PART# : DL136T-XX-10.16
