Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96

    Buy cheap Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96 from wholesalers

    Buy cheap Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96 from wholesalers
    • Buy cheap Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96 from wholesalers

    Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96

    Ask Lasest Price
    Brand Name : DELI
    Model Number : DL350R-XX-3.5/3.96
    Payment Terms : T/T, Western Union
    Supply Ability : 10000
    Delivery Time : 2DAYS
    • Product Details
    • Company Profile

    Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96

    MATERIAL
    Pitch:3.5/3.96MM
    Poles: 2P,3P
    Screw:M2, Steel, Zinc plated
    Wire guard: phosphor bronze, Ni platedor stainless steel
    Pin header:Brass,Tin plated
    Housing:PA66. UL94V-0
    ELECTRICAL
    Rated voltage:130V/300V
    Rated current:10A
    Withstanding voltage:AC1250V/1Min
    Wire range:24-18AWG
    MECHANICAL
    Temperature range:-40℃-- +105℃
    MAX soldering:+250℃ for 5 sec
    Torque:0.2Nm(1.8 lb.in)
    Strip length:4.5-5mm
    Terminal Block PCB Connector M2 Steel Zinc Plated Screw 24-18AWG DL350R-XX-3.5/3.96
    DeLi Electronics Technology Co., Ltd
    PART# : DL350R-XX-3.5/3.96
