    5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing

    Ask Lasest Price
    Brand Name : DELI
    Model Number : DL332K-XX-5.0
    Payment Terms : T/T, Western Union
    Supply Ability : 10000
    Delivery Time : 2DAYS
    • Product Details
    • Company Profile

    5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing

    MATERIAL
    Pitch:5.0MM
    Poles: 2P,3P
    Screw:M2.5,Steel, Zinc plated
    Wire cage:Steel, Zinc plated
    Wire guard: phosphor bronze, Ni plated
    Housing:PBT. UL94V-0
    ELECTRICAL
    Rated voltage:300V/250V
    Rated current:10A/17A
    Withstanding voltage:AC2000V/1Min
    Wire range:24-14AWG
    MECHANICAL
    Temperature range:-30℃-- +120℃
    MAX soldering:+250℃ for 5 sec
    Torque:0.4Nm(3.5 lb.in)
    Strip length:4.5mm
    5 Pole Terminal Block Connector 10A/17A DL332K-XX-5.0 With PBT UL94V-0 Housing
    DeLi Electronics Technology Co., Ltd
    PART# : DL332K-XX-5.0
