    Right Angle Electrical Connector Blocks , Wire To Board Connector DL202-XX-10.0

    Ask Lasest Price
    Brand Name : DELI
    Model Number : DL202-XX-10.0
    Payment Terms : T/T, Western Union
    Supply Ability : 10000
    Delivery Time : 2DAYS
    • Product Details
    • Company Profile

    Right Angle Electrical Connector Blocks , Wire To Board Connector DL202-XX-10.0

    MATERIAL
    Pitch:10.0MM
    Poles: 1P-xxP
    Pin header: Brass , Tin plated
    Wire guard: Stainless Steel
    Housing:PA66. UL94V-0
    ELECTRICAL
    Rated voltage:300V/750V
    Rated current:12A/16A
    Withstanding voltage:AC2500V/1Min
    Wire range:20-12AWG
    MECHANICAL
    Temperature range:-40℃-- +105℃
    MAX soldering:+250℃ for 5 sec
    Strip length:10-11mm
    Right Angle Electrical Connector Blocks , Wire To Board Connector DL202-XX-10.0
    DeLi Electronics Technology Co., Ltd
    PART# : DL202-XX-10.0
