Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16

    Buy cheap Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16 from wholesalers

    Buy cheap Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16 from wholesalers
    • Buy cheap Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16 from wholesalers
    • Buy cheap Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16 from wholesalers

    Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16

    Ask Lasest Price
    Brand Name : DELI
    Model Number : DL134C-XX-10.16
    Payment Terms : T/T, Western Union, paypal
    Supply Ability : 10000
    Delivery Time : 3-5days
    Price : negotiation
    • Product Details
    • Company Profile

    Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16

    Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
    MATERIAL
    Poles:1P--xxP
    Screw:M4, Steel,Zinc plated
    Wire cage:Brass, Ni plated
    Pin header:Brass,Tin plated
    Housing:Housing:PA66. UL94V-0


    ELECTRICAL
    Rated voltage:600VV/750V
    Rated current:60A/57A
    Withstanding voltage:AC3000V/1Min
    Wire range:20-6AWG/10M ㎡

    MECHANICAL
    Temperature range:-40℃-- +105℃
    MAX soldering:+250℃ for 5 sec
    Torque:
    1.2Nm(10.5 lb.in)
    Strip length:10mm
    Screw Terminal Block Connector 10.16mm Pitch 1P-xxP 600V 60A PCB DL134C-XX-10.16
