Headers 5.2A 5.54mm Tiger Claw Socket Strip SSM-110-L-SV-P

Ask Lasest Price
Brand Name :	SAMTEC
Model Number :	SSM-110-L-SV-P-TR
Certification :	CE/ RoHS
Price :	To be negotiated
Payment Terms :	T/T, Western Union ,paypal
Supply Ability :	10,000PCS
Delivery Time :	in stock 2-3days

Add to Cart

Product Details
Company Profile

Headers 5.2A 5.54mm Tiger Claw Socket Strip SSM-110-L-SV-P

SSM-110-L-SV-P-TR Headers & Wire Housings .100" (2.54 mm) Tiger Claw Surface Mount Socket Strip

TIGER CLAW™SURFACE MOUNT SOCKET

For complete specifications and recommended PCB layouts

Specifications

Product Attribute	Attribute Value
Manufacturer:	Samtec
Product Category:	Headers & Wire Housings
RoHS:	Details
Product:	Headers
Type:	Socket
Number of Positions:	10 Position
Pitch:	2.54 mm
Number of Rows:	1 Row
Row Spacing:	-
Termination Style:	Solder
Mounting Angle:	Straight
Contact Gender:	Socket (Female)
Mating Post Length:	-
Termination Post Length:	-
Series:	SSM
Tradename:	Tiger Claw
Minimum Operating Temperature:	- 55 C
Packaging:	Cut Tape
Packaging:	Reel
Contact Type:	-
Current Rating:	5.2 A
Housing Material:	Liquid Crystal Polymer (LCP)
Brand:	Samtec
Contact Material:	Phosphor Bronze
Flammability Rating:	UL 94 V-0
Housing Color:	Black
Housing Gender:	-
Latching Type:	Unlatched
Product Type:	Headers & Wire Housings
Factory Pack Quantity:	325
Subcategory:	Headers & Wire Housings
Unit Weight:	0.013263 oz

Insulator Material:

Black Liquid Crystal Polymer

Contact Material:

Phosphor Bronze

Plating:

Au or Sn over

50 µ" (1.27 µm) Ni

Current Rating (SSM/TSW):

5.2 A per pin

(2 pins powered)

Voltage Rating:

405 VAC / 572 VDC

Operating Temp Range:

-55 °C to +125 °C with Gold

-55 °C to +105 °C with Tin

Insertion Depth:

SV/DV is (4.34 mm) .171" to

(7.24 mm) .285" or pass-through

from top; (5.56 mm) .219" plus

board thickness minimum from

bottom; SH/DH is (4.34 mm).171" to (6.35 mm) .250"

Normal Force:

125 grams (1.21 N) average

RoHS Compliant:

Yes

HIGH-SPEED CHANNEL PERFORMANCE

–F

=Gold flash

on contact,

Matte Tin on tail

–L

= 10 µ" (0.25 µm)

Gold on contact,

Matte Tin on tail

–S

= 30 µ" (0.76 µm)

Gold on contact,

Matte Tin on tail
