    1608KL-05W-B69-L50 10.9CFM 24VDC Axial Bearing DC Fans 40x20mm

    Ask Lasest Price
    Brand Name : NMB TECHNOLOGIES
    Model Number : 1608KL-05W-B69-L50
    Certification : CE/ RoHS
    Price : To be negotiated
    Payment Terms : T/T, Western Union ,paypal
    Supply Ability : 10,000PCS
    Delivery Time : in stock 2-3days
    • Product Details
    • Company Profile

    1608KL-05W-B69-L50 10.9CFM 24VDC Axial Bearing DC Fans 40x20mm

    1608KL-05W-B69-L50 DC Fans DC Axial Fan 40x20mm 24VDC

    10.9CFM Rib Tachometer 3 Lead Wires

    Detailed Specifications

    Fan Size: 40[mm]

    Fan Width: 20[mm]

    Max. Air Flow: 10.95 [CFM]

    Max. Air Flow: 0.31 [m3/min]

    Max. Static Pressure: 0.378 [In H2O]

    Fan Speed: 9500 [RPM]

    Noise: 36 [dB]

    Life Expectancy: 25 degree C 50,000 Hours [L10]

    Bearing Type: Ball Bearing

    Speed Control: - Nominal

    Voltage: 24[V]

    Operating Voltage Lower: 20 [V]

    Operating Voltage Upper: 25.2 [V]

    Current: 0.17 [A]

    Input Power: 2.04 [W]

    Mass: 25 [g]

    IP Rating: Standard



    ManufacturerNMB Technologies
    Manufacturers Part #1608KL-05W-B69-L50
    Lead Timein stock 2-3days after payment.
    Industry Aliases1608KL05WB69L50
    Sub-Categories Thermal Management Blowers and Fans
    Selling Alternatives 04020KA-24P-AT-00, 04020VA-24P-AT-00
    Series1608KL
    Factory Pack Quantity350
