    SC-88 6 Leads PUSB2X4Y ESD Protection Rectifier Diode 0.85pF

    Ask Lasest Price
    Brand Name : Nexperia
    Model Number : PUSB2X4YH
    Certification : CE/ RoHS
    Price : To be negotiated
    Payment Terms : T/T, Western Union ,paypal
    Supply Ability : 10,000PCS
    Delivery Time : in stock 2-3days
    • Product Details
    • Company Profile

    SC-88 6 Leads PUSB2X4Y ESD Protection Rectifier Diode 0.85pF

    PUSB2X4Y ESD protection for high-speed interfaces plastic TVS Diode
    surface-mounted SC-88 package 6 leads
    1. Product profile
    1.1 General description
    The device is designed to protect high-speed interfaces
    such as USB 2.0 ports against ElectroStatic Discharge (ESD).
    The device includes four high-level ESD protection diode structures for high-speed signal lines.
    It is encapsulated in a very small SOT363 (SC-88) Surface-Mounted Device (SMD) plastic package.
    All signal lines are protected by a special diode configuration offering ultra low line capacitance of 0.85 pF maximum.
    This configuration provides protection to downstream components from ESD voltages up to 12 kV
    contact according to IEC 61000-4-2, level 4.
    1.2 Features and benefits
     System ESD protection for USB 2.0
     All signal lines with integrated rail-to-rail clamping diodes for downstream ESD protection of 12 kV according to IEC 61000-4-2, level 4
     Line capacitance of 0.85 pF maximum for each channel 1.3
    2. Applications
    The device is designed for receiver and transmitter port protection in:
     Portable devices
     TVs, monitors
     DVD recorders and players
     Notebooks, mother boards, graphic cards and ports
     Set-top boxes and game consoles
    SC-88 6 Leads PUSB2X4Y ESD Protection Rectifier Diode 0.85pF
